描述
- Honeywell Balanced Hydronic Zone Valve Actuator
- VC4010 Series
- Support Body:2-Way & 3-Way
- Voltage:110V
- Wiring:2 wire + com. for SPST stat. (二/三線共用)
- Connection:MolexTM connector
- *具備MolexTM connector系列驅動馬達(VC4010 & VC4012)已停產, 新規格(VC4011, VC4013)皆為從驅動馬達內部直接出線
Honeywell VC4 Series Balanced Hydronic Zone Valve Actuator
VC4010/VC4012 系列已停產. 該產品皆為庫存目前主要以VC4011/VC4013為主
| 型號 | 口徑 | 閥體結構 | 驅動器接線 | 電壓 | 備註 |
|---|---|---|---|---|---|
| VC4013MP6000 | 1" | 三通閥 | 2/3線共用 | 220V | replace VC4012MP6000 |
| VC4013MJ6000 | 3/4" | 三通閥 | 2/3線共用 | 220V | replace VC4012MJ6000 |
| VC4013AP1000 | 1" | 二通閥 | 2/3線共用 | 220V | replace VC4012AP1000 |
| VC4013AK1000 | 3/4" | 二通閥 | 2/3線共用 | 220V | replace VC4012AK1000 |
| VC4011MP6000 | 1" | 三通閥 | 2/3線共用 | 110V | replace VC4010MP6000 |
| VC4011MJ6000 | 3/4" | 三通閥 | 2/3線共用 | 110V | replace VC4010MJ6000 |
| VC4011AP1000 | 1" | 二通閥 | 2/3線共用 | 110V | replace VC4010AP1000 |
| VC4011AK1000 | 3/4" | 二通閥 | 2/3線共用 | 110V | replace VC4010AK1000 |
| VC4012 | - | - | 2/3線共用 | 220V | 驅動馬達(無閥體) w/ Molex connector |
| VC4010 | - | - | 2/3線共用 | 110V | 驅動馬達(無閥體) w/ Molex connector |
| VC4013 | - | - | 2/3線共用 | 220V | 驅動馬達(無閥體) replace VC4012 |
| VC4011 | - | - | 2/3線共用 | 110V | 驅動馬達(無閥體) replace VC4010 |
