哈里斯 銀焊條(罐裝) Harris Safety-Silv 56 High-silver Brazing Alloy 5635

  • 美國品牌
  • 銀合金銲條
  • 成分: 銅:22%, 鋅:17%, 錫:5%, 銀:56%
  • 請注意本產品因國際金屬價格影響故會有波動
  • 本產品只接受大量採購(MOQ=48), 不零售
貨號: 5635 分類: , , , 標籤: ,

描述

Safety-Silv® 56 is a high silver content alloy that produces premium quality brazes. It is free flowing with unsurpassed capillary attraction and deep penetration with high ductility. Safety-Silv® 56 is suitable for use in the food service industry. The silver color is an excellent match for stainless steel and silverware applications.

Features

  • High silver cadmium-free brazing alloy
  • Produces premium quality brazes
  • Free flowing with unsurpassed capillary attraction
  • Deep penetration with high ductility
  • Excellent fluidity promotes penetration
  • Silver color is excellent match for stainless steel and silverware applications in the foodservice industry.
  • Meets NSF/ANSI Standard 51 for food equipment materials
  • Complies with the EU Reach & RoHS directive

Typical Applications

  • Food processing industry
  • Stainless steel brazing
  • Silverware applications

額外資訊

品牌

NOMINAL CHEMICAL COMPOSITION%:

Silver 55.0 – 57.0
Copper 21.0 – 23.0
Zinc 15.0 – 19.0
Tin 4.5-5.5
Other (Total) 0.15
TYPICAL PHYSICAL PROPERTIES:

Solidus 1145ºF (618°C)
Liquidus 1205°F (652°C)
Brazing Range 1205°F- 1400°F (650°C -760°C)
Electrical Conductivity 8.32 (%IACS)
Density 4.93 (t.o./cu.in.).
